Photography for this item is being produced.
Stainless Steel
Rectangular tubes, ASTM A554
WP-720
Specifications
- SKU
- WP-720
- Division
- Industrial
- Category
- Pipes and tubes
- Grade
- 304 / 316
- Standard
- ASTM A554
- Size
- 20 × 10, 30 × 15, 40 × 20, 50 × 25, 60 × 30, 80 × 40, 100 × 50, 25.4 × 50.8, 50.8 × 101.6 mm
- Finish
- 2B, brush (No. 400), satin, No. 600 standard polish, No. 800 super mirror
- Length
- 6 m standard; 3 m; custom length on request
- Material
- Stainless steel
- Standard
- ASTM A554
- Wall thickness
- 1.0 (custom), 1.2, 1.5, 1.65, 2, 2.5, 3, 3.5, 4 mm — not every pairing is stocked
Dimensions, weights and finish appearance shown here are nominal and for guidance. Confirm the delivered specification against the mill certificate and an approved physical sample.
Overview
Rectangular ornamental tube to ASTM A554 from 20 × 10 mm to 100 × 50 mm, plus the imperial 1" × 2" and 2" × 4" sections, in walls from 1.2 mm to 4 mm, polished in-house.
Technical description
Stock ranges are as listed in the Hidayath Metal Industries company profile; custom lengths are cut on request. Confirm grade, size and quantity on enquiry.
Related products
Need this quoted?
Send the quantity, dimensions and finish you need. The request arrives with this item already attached.
