Expanded metal HEX 62
HEX-62
Specifications
- SKU
- HEX-62
- Division
- Architectural
- Category
- Expanded metal
- Finish
- Mill finish; other surface treatments on request
- Material
- Stainless steel, aluminium, mild steel
- Open area
- 45 %
- Strand width
- 6 mm
- Sheet thickness
- Stainless steel 1.2–2 mm · aluminium 1.5–4 mm · mild steel
- Pattern variations
- SWD 16 / 20 / 24 / 28 mm · strand 4 / 8 / 12 / 14 mm · thickness 2, 3, 4 mm
- Pattern (LWD × SWD)
- 62 × 22 mm
Dimensions, weights and finish appearance shown here are nominal and for guidance. Confirm the delivered specification against the mill certificate and an approved physical sample.
Overview
A 62 mm diamond with a 6 mm strand and 45 % open area. The pattern gives privacy while letting light and air through, and is the usual choice for facades, parapets and balustrade infill.
Technical description
Line limits from the Hidayath Metal Industries company profile: maximum working width 1550 mm, long-way diamond 15 to 150 mm, short-way diamond 7 to 60 mm, strand width 1 to 9 mm, sheet thickness 1 to 5 mm. Other pattern sizes are made to order — confirm the pattern, material and quantity on enquiry.
Applications
- Facades and sunscreens
- Ceilings
- Partitions
- Column covers
- Safety and security screens
