Expanded metal HEX 92
HEX-92
Specifications
- SKU
- HEX-92
- Division
- Architectural
- Category
- Expanded metal
- Finish
- Mill finish; other surface treatments on request
- Material
- Stainless steel, aluminium
- Open area
- 65 %
- Strand width
- 5 mm
- Sheet thickness
- Stainless steel 0.8–1.5 mm · aluminium 1.5–4 mm
- Pattern variations
- SWD 28 / 32 / 36 / 40 mm · strand 10 / 14 / 18 / 20 mm · thickness 2, 3, 4 mm
- Pattern (LWD × SWD)
- 92 × 28 mm
Dimensions, weights and finish appearance shown here are nominal and for guidance. Confirm the delivered specification against the mill certificate and an approved physical sample.
Overview
A 92 mm diamond with a narrow 5 mm strand and 65 % open area, cut from thinner sheet than the other large patterns. A light, open screen for facades and ceilings where reflectance and airflow matter more than mass.
Technical description
Line limits from the Hidayath Metal Industries company profile: maximum working width 1550 mm, long-way diamond 15 to 150 mm, short-way diamond 7 to 60 mm, strand width 1 to 9 mm, sheet thickness 1 to 5 mm. Other pattern sizes are made to order — confirm the pattern, material and quantity on enquiry.
Applications
- Facades and sunscreens
- Ceilings
- Partitions
- Column covers
- Safety and security screens
