Photography for this item is being produced.
Cable metal fabric HMF-M4362
HMF-M4362
Specifications
- SKU
- HMF-M4362
- Division
- Architectural
- Category
- Metal fabric
- Subcategory
- Cable
- Weight
- 9.29 kg/m²
- Material
- Stainless Steel
- Open area
- 51.4 %
- Rod pitch
- 7 mm
- Cable pitch
- 80 mm
- Rod diameter
- 3 mm
- Max thickness
- 7 mm
- Cable diameter
- 2 mm x 4 mm
Dimensions, weights and finish appearance shown here are nominal and for guidance. Confirm the delivered specification against the mill certificate and an approved physical sample.
Overview
HMF-M4362 is a cable stainless steel metal fabric: 2 mm x 4 mm cables at 80 mm pitch, 3 mm rods at 7 mm pitch, 51.4 % open area, 7 mm maximum thickness and 9.29 kg/m² theoretical weight.
The figures are those printed in the Hidayath mesh catalogue. Metal fabric of this construction is used in architecture indoors and outdoors, and where the aperture suits, in industrial separation and filtration, insect screening, animal fencing and security guards. Confirm panel size, edge finish and fixing on enquiry.
Applications
- Architectural cladding and screens, indoor and outdoor
- Industrial separation and filtration
- Insect screening and animal fencing
- Security mesh: window, machine and stairwell panel guards
- Fireplace screens, bird screens and gutter guards
- Ventilation and RFI shielding
